Zoom PFX-9003 User Manual

Effect Types and Parameters
ZOOM PFX-9003
47
LOWBST
0 – 10
Emphasizes the low frequency range.
SIZE
1 – 10
Adjusts the size of the simulated space.
WETLVL
0 – 30
Adjusts the effect sound mixing amount.
DRYLVL
0 – 30
Adjusts the direct sound mixing amount.
TYPE
1 – 16
Selects the pitch change type caused by ARRM (see
table 4).
Table 4: TYPE
Setting Output pitch
1
Semitone lower → original pitch
2
Original pitch → semitone lower
3
Doubling → detune + original pitch
4
Detune + original pitch → doubling
5
Original pitch → 1 octave higher
6
1 octave higher → original pitch
7
Original pitch →2 octaves lower
8
2 octaves lower → original pitch
9
1 octave lower + original pitch → 1 octave higher + original pitch
10
1 octave higher + original pitch → 1 octave lower + original pitch
11
Perfect fifth lower + original pitch → perfect fourth higher + original pitch
12
Perfect fourth higher + original pitch → perfect fifth lower + original pitch
13
0 Hz + original pitch → 1 octave higher
14
1 octave higher → 0 Hz + original pitch
15
0 Hz + original sound → 1 octave higher + original pitch
16
1 octave higher + original sound → 0 Hz + original pitch
◆ REV module
HALL
Reverb effect which simulates the acoustics of a concert hall.
Parameter 1: TIME Parameter 2: TONE
Parameter 3: MIX [A]
ROOM
Reverb effect which simulates the acoustics of a room.
Parameter 1: TIME Parameter 2: TONE
Parameter 3: MIX [A]
SPRING
Reverb effect which simulates a spring type reverb machine.
Parameter 1: TIME Parameter 2: TONE
Parameter 3: MIX [A]
MN-DLY
Mono delay with a duration of up to 1.9 seconds.
Parameter 1: TIME Parameter 2: FB
Parameter 3: MIX [A]
PP-DLY
When two amplifiers are used, this serves as a ping-pong delay effect with a
duration of up to 1.9 seconds. When one amplifier is used, the effect is a mono
delay.
Parameter 1: TIME Parameter 2: FB
Parameter 3: MIX [A]
