Zoom R24 User Manual

14
Audio interface manual
Control surface functions quick reference guide
These functions work with Cubase LE 5, Cubase 5, Logic Pro, SONAR, Ableton Live
and Digital Performer.
Control Explanation
Fadersection
Statuskeys
Turnsmute,soloorrecordarmingon/offforthetrack
Faders
Controlsthevolumeofthecorrespondingtracks
MASTERFader
Mastervolumeoperation
Displaysection Soft keys Changefunctionsofstatuskeys/Endconnection(EXIT)
Transportsection
Cursorkeys
Performsthesamefunctionsasthecomputerarrowkeys
1
DIAL Movestheprojectcursorposition
2
REWkey
Rewind
FFkey
Fastforward
STOPkey
Stop
PLAYkey
Play
RECkey
Record
AUTO PUNCH I/Okey
Dependsonthe[F1]keysetting
A-B REPEATkey
Dependsonthe[F2]keysetting
(marker)key
Dependsonthe[F3]keysetting
(marker)key
Dependsonthe[F4]keysetting
MARK/CLEARkey
Dependsonthe[F5]keysetting
Controlsection
1-8Trkey
Movesonebankforward
9-16Trkey
Movesonebankbackward
1
Scrolls window in Digital Performer
2
No function in Digital Performer

Zoom R24 Specifications

General

Sample rate	96 kHz
Channels quantity	10 channels
Digital sound processing	24 bit
USB 2.0 ports quantity	1
DJ mixer	-
Product color	Silver

Weight and Dimensions

Depth	237.1 mm
Width	376 mm
Height	52.2 mm
Weight	1300 g
