Zoom R24 User Manual

16
Audio interface manual
NOTE
Theinspectordisplaysinformationaboutthetrack
currently selected.If itdoesnotdisplay anything
clickonatracktoseethattrack’sstatus.
Create a new audio track
5
Set-up the audio tracks that were
made as follows.
The project file save location window is displayed.
4
Set the save location and click the
“OK” button (“Choose” button on
Mac OS X).
This will create a new project and the project
window where most Cubase LE 5 operations are
conducted will open.
Inspector area allows setting of detailed track
information
If the inspector is not shown, click
here to show/hide the inspector
Select the track input/output bus.
The names of the R24 busses assigned in
the VST Connections (Devices menu) will be
displayed.
Click here to choose a different bus from the
menu.
To add a new audio track, select “Add Track” from
the “Project” menu and then choose “Audio” from
the sub-menu that appears.

Zoom R24 Specifications

General

Sample rate	96 kHz
Channels quantity	10 channels
Digital sound processing	24 bit
USB 2.0 ports quantity	1
DJ mixer	-
Product color	Silver

Weight and Dimensions

Depth	237.1 mm
Width	376 mm
Height	52.2 mm
Weight	1300 g
