Zoom R24 User Manual

28
Audio interface manual
Working with patches
After making many changes, you can restore a patch to its pre-edited settings by
initializing it. This will return it to its factory preset condition.
1
Press
EFFECT
.
Turning effects on/off
Insert effect
Send return effect
Patch initialization (factory reset)
EFFECT
>
INITIAL
Selecting insert effect/reverb patches
To use an insert effect, select an algorithm and
a patch.
To use a send reverb effect, select a patch.
(Reference:
Operation Manual
)
Editing patches (EDIT)
By adjusting effect module parameters and
levels, you can create the desired result. (Refer-
ence:
Operation Manual
)
Importing patches (IMPORT)
All effect algorithms (and reverb patches) or
a single one can be imported from a selected
project on the R24.
(Reference: Operation Manual )
In audio interface mode, one complete set of effect
data is saved for the mode. There are no project
based settings.
Saving patches (SAVE)
Edited patches can be saved.
(Reference: Operation Manual )
Initializing patches (INITIAL)
Restores patches to their original factory set-
tings (only available in audio interface mode).
Changing patch names (RENAME)
The name of the currently selected patch can
be changed.
Patch operation menu
Patch operations
For both insert and send return effects
The following example is of an insert
effect.
Press the beneath .
Press the
beneath .
Turn the effect
On
.
2
Select
INITIAL
.
3
Press
ENTER
.
Change
menu
4
Select
YES
.
Press
ENTER
.
Change
menu
Change

Zoom R24 Specifications

General

Sample rate	96 kHz
Channels quantity	10 channels
Digital sound processing	24 bit
USB 2.0 ports quantity	1
DJ mixer	-
Product color	Silver

Weight and Dimensions

Depth	237.1 mm
Width	376 mm
Height	52.2 mm
Weight	1300 g
