Zoom R24 User Manual

22
Audio interface manual
HINT
• The USB cable can be connected even when the
computer or the R24 is on.
• If the R24 is connected when off, it can be run on
USB bus power.
• Project data is stored in folders for each project
in the PROJECT folder in the ZOOM_R24 folder.
Audio recordings are stored as WAV files in
the “AUDIO” subfolders of each project folder.
Each AUDIO folder also contains a file called
“PRJINFO.TXT” that lists the names of files
assigned to tracks.
• Master tracks and stereo tracks are stereo
WAV les.
• To copy a WAV le from a computer, copy it to
the AUDIO subfolder of the desired project folder
Use the R24 to assign the les to tracks.
In the “Import Options” window
click the “Copy Files to Working
Directory” check box, and click the
OK button.
7 9
Select the le (or les) that you
wish to import from the “AUDIO”
folder and drag and drop them into
the Cubase LE 5 project window.
When a file is dragged and dropped, a
window will open asking how Cubase
LE 5 should place the file.
When dragging multiple les at one
time, select either “Different Tracks” or
“One Track” as the import method.
8
Generally, select “Different Tracks” to automati-
cally create one track for each file. The files will
be arranged vertically in the project window.
Select “One track” to create one track with the
audio files arranged horizontally.
This window where you can select the import
method appears.
The audio les are loaded into
Cubase LE 5 tracks.

Zoom R24 Specifications

General

Sample rate	96 kHz
Channels quantity	10 channels
Digital sound processing	24 bit
USB 2.0 ports quantity	1
DJ mixer	-
Product color	Silver

Weight and Dimensions

Depth	237.1 mm
Width	376 mm
Height	52.2 mm
Weight	1300 g
