Zoom R24 User Manual

4
Audio interface manual
Multifunction tuner
In addition to standard chromatic tuning,
the on-board multifunction tuner also sup-
ports 7-string guitar, 5-string bass and
various drop tunings.
Comprehensive built-in mixer
Using the R24’s mixer, you can make a
mix for monitoring. When simultaneously
recording guitar and vocals, for example,
you can adjust volume balance, panning
and reverb levels.
Moreover, you can also adjust the balance
between the built-in mixer and the sound
sent from a computer.
Versatile effect functions
Built-in insert effects can be applied to
specific channel paths, and two-types
of send/return effects work via the mixer
send/return. These effects can be applied
when recording, of course, but they can
also be applied to only the monitor output.
For example, when recording vocals, you
can apply reverb only to the monitor sig-
nal to make singing easier.
Supports input from a variety of
sources, including guitars, mics and
line level instruments
The 8 onboard jacks accept XLR and
standard phone plugs and include one
high-impedance input and two inputs with
phantom power (24V or 48V).
Many sources are supported from high-
impedance guitars and basses to dynamic
and condenser microphones and line-
level devices like synthesizers. In addition,
built-in high- performance condenser
microphones are convenient for recording
acoustic guitars and vocals.

Zoom R24 Specifications

General

Sample rate	96 kHz
Channels quantity	10 channels
Digital sound processing	24 bit
USB 2.0 ports quantity	1
DJ mixer	-
Product color	Silver

Weight and Dimensions

Depth	237.1 mm
Width	376 mm
Height	52.2 mm
Weight	1300 g
