RT60 Rough Terrain Crane 09 - 13
10) RATED CAPACITY INDICATOR (RCI)
Rated Capacity Indicator with visual and audible warning system and automatic
function disconnects.
If the actual load approaches the rated one, the buzzer sends out visual and audible
warning. If the actual load reaches the rated one, all dangerous movements are
switched off automatically.
The rated capacity indicator also can limit the working range (including working radius,
boom angle, lifting height and swing range etc.).
Pictographic display includes boom angle, moment ratio, boom length, defaulted hook
weight, actual working radius, swing angle, actual load, allowable load, jib offset, line
parts, boom status, outrigger information, “On Tires” indication and percentage of
allowable load and hydraulic system pressure registered by bar graph.
11) OUTRIGGERS
H-type hydraulic outriggers can be operated in the cab simultaneously or
independently. Each vertical jack is equipped with a two-way hydraulic lock to ensure
that the outriggers can be secured reliably during working or traveling.
Outrigger boxes are directly welded onto the chassis frame.
The outriggers can be completely extended, intermediately extended or completely
retracted.
Longitudinal distance between outriggers: 22.6 ft (6900 mm)
Transversal distance between outriggers:
Completely extended: 22.6 ft (6900 mm)
Intermediately extended: 15.8 ft (4830 mm)
Completely retracted: 9.1 ft (2760 mm)
