ZTE H1600 Maintenance Management Guide
Table 4-4 Uplink Mode
Parameter
Description
WAN preferred +Mobile Backup
WAN as primary, xDSL as secondary, and LTE backup as
tertiary link.
xDSL preferred + Mobile Backup
xDSL as primary, WAN as secondary, and LTE backup as
tertiary link.
WAN only + Mobile Backup
Only WAN can be used as the primary link, and LTE as the
backup link.
xDSL only + Mobile Backup
Only xDSL can be used as the primary link, and LTE as the
backup link.
3. Click Apply button to apply the changes.
4.3 Configure the QoS Global Parameters
The uplink QoS configuration can be used to prioritize TR069, VoIP and INTERNET ser-
vices and configure the QoS parameters of each service to ensure the QoS guarantee
of high-priority services.
1. On the main page of the ZTE H1600, select Internet > QoS > QoS Global Configu-
ration to open the QoS Global Configuration page, see Figure 4-12.
Figure 4-12 QoS Global Configuration page
2. Set radiobox On to enable QoS function.
3. Click Apply button to apply the changes.
4.4 Configure the Security
4.4.1 Configure the Filter Criteria
By configuring URLs and MAC address filtering entries, you can allow or reject LAN
users on the user side to access specific URL/MAC addresses.
Steps
