Dimension GS-3012 Gigabit Ethernet Switch

14-2 Link Aggregation

[(0000,00-00-00-00-00-00,0000,00,0000)] [(0000,00-00-00-00-00-00,0000,00,0000)]

Local switch

0000 00-00-00-00-00 0000 00 0000

System priority Local switch MAC address Key Port Priority

Port Number

Peer switch

0000 00-00-00-00-00 0000 00 0000

System priority MAC address Key Port Priority

Port Number

Figure 14-1 Aggregation ID

14.2 Link Aggregation Protocol Status

Click Advanced Application, Link Aggregation in the navigation panel to display the Link Aggregation

Protocol Status screen.

Figure 14-2 Link Aggregation: Link Aggregation Protocol Status

This is “0” as it is the aggregator ID for the link aggregation group, not the individual port.
