Dimension GS-3012 Gigabit Ethernet Switch
Cluster Management 25-3
Table 25-2 Cluster Management Status
LABEL DESCRIPTION
Status This field displays:
o Online (the cluster member switch is accessible)
o Error (for example the cluster member switch password was changed or the switch
was set as the manager and so left the member list, etc.)
o Offline (the switch is disconnected - Offline shows approximately 1.5 minutes after
the link between cluster member and manager goes down).
25.2.1 Cluster Member Switch Management
Go to the Clustering Management Status screen of the cluster manager switch and then select an Index hyperlink
from the list of members to go to that cluster member switch's web configurator home page. This cluster member
web configurator home page and the home page that you'd see if you accessed it directly are different (see Figure
25-3).
Figure 25-3 Cluster Member Web Configuration Screen
Uploading Firmware to a Cluster Member Switch
You can use FTP to upload firmware to a cluster member switch through the cluster manager switch as shown in
the following example.
Cluster Manager
Menus
Cluster Member
Menus
