Dimension GS-3012 Gigabit Ethernet Switch
Command Examples 29-15
Figure 29-29 spq Command Example
29.8.11 wrr
Syntax:
wrr
wrr <wt1> <wt2> ... <wt8>
where
Enables WRR on the switch.
<wt1> <wt2>
... <wt8>
Sets the interface to use Weighted Round Robin queuing. A weight value of
one to eight is given to each variable from wt 1 to wt 8.
An example is shown next.
Enable port two and ports six to twelve for configuration.
Enable Weighted Round Robin queuing on the interface.
Set the queue weights from Q0 to Q7.
Figure 29-30 wrr Command Example
29.8.12 egress set
Syntax:
egress set <port-list>
where
<port-list>
Sets the outgoing traffic port list for a port-based VLAN.
An example is shown next.
Enable port-based VLAN tagging on the switch.
Enable ports one, three, four and five for configuration.
Set the outgoing traffic ports as the CPU (0), seven (7), eight (8) and nine (9).
Figure 29-31 egress set Command Example
GS-3012# configure
GS-3012(config)# interface 2,6-12
GS-3012(config-interface)# wrr
GS-3012(config-interface)# wrr 8 7 6 5 4 3 2 1
GS-3012(config)# vlan-type port-based
GS-3012(config)# interface 1,3-5
GS-3012(config-interface)# egress set 0,7-9
GS-3012(config)# interface 1,3-5
GS-3012(config-interface)# spq
