Chapter 2 The Web Configurator
LTE Series User’s Guide
39
2.2.1.2 Navigation Panel
Use the menu items on the navigation panel to open screens to configure Zyxel Device features. The
following tables describe each menu item.
Table 11 Navigation Panel Summary
LINK TAB FUNCTION
Home Use this screen to configure basic Internet access and wireless settings.
This screen also shows the network status of the Zyxel Device and
computers/devices connected to it.
Network Setting
Broadband Broadband Use this screen to view and configure ISP parameters, WAN IP address
assignment, and other advanced properties.
WAN Backup Use this screen to configure your Zyxel Device’s Internet settings if the
cellular connection is down.
Ethernet WAN Use this screen to convert the LAN port as WAN port, or restore the WAN
port to LAN port.
Cellular WAN Use this screen to configure an LTE WAN connection that includes the
Access Point Name (APN) provided by your service provider.
Cellular SIM Use this screen to enter a PIN for your SIM card to prevent others from
using it.
Cellular Band Use this screen to configure the LTE frequency bands that can be used
for Internet access as provided by your service provider.
Cellular PLMN Use this screen to view available PLMNs and select your preferred
network.
Cellular IP
Passthrough
Use this screen to enable IP Passthrough mode (bridge mode).
Note: This screen is not available when the fourth LAN port acts
as an Ethernet WAN port. See Table 1 on page 16 for the
feature differences of the Zyxel Devices.
Wireless General Use this screen to configure the wireless LAN settings and WLAN
authentication/security settings.
Guest/More AP Use this screen to configure multiple BSSs on the Zyxel Device.
MAC
Authentication
Use this screen to block or allow wireless traffic from wireless devices of
certain SSIDs and MAC addresses to the Zyxel Device.
WPS Use this screen to configure and view your WPS (WiFi Protected Setup)
settings.
WMM Use this screen to enable or disable WiFi MultiMedia (WMM).
Others Use this screen to configure advanced wireless settings.
WLAN Scheduler Use this screen to create rules to schedule the times to permit Internet
traffic from each wireless network interfaces.
Channel Status Use this screen to scan wireless LAN channel noises and view the results.
Home
Networking
LAN Setup Use this screen to configure LAN TCP/IP settings, and other advanced
properties.
Static DHCP Use this screen to assign specific IP addresses to individual MAC
addresses.
UPnP Use this screen to turn UPnP and UPnP NAT-T on or off.
