Chapter 4 Tutorials
LTE Series User’s Guide
66
computer B (in N2 network), the traffic is sent to the Zyxel Device’s WAN default gateway by default. In
this case, B will never receive the traffic.
You need to specify a static routing rule on the Zyxel Device to specify R as the router in charge of
forwarding traffic to N2. In this case, the Zyxel Device routes traffic from A to R and then R routes the
traffic to B.
This tutorial uses the following example IP settings:
Table 12 IP Settings in this Tutorial
DEVICE / COMPUTER IP ADDRESS
The Zyxel Device’s LAN 192.168.1.1
A 192.168.1.34
R’s N1 192.168.1.253
R’s N2 192.168.10.2
B 192.168.10.33
