1.
2.
3.
4.
5.
6.
RJ-45 LAN 10/100BaseT connector
12 V / 0,75 A DC supply terminal board (only if PoE is not used)
Restart/Factory reset button
Binary input/output terminal board (for application control)
Micro SD card slot
Logic inputs and outputs
Tip
External doorbell button or Relay connection guides are available at faq.
.2n.cz
Warning
Do not remove the backside rubber sealing as it improves the accoustic
properties of the product during wall mounting.
