3D Systems CubePro - Compare Print Jet Z-Gaps

Compare Print Jet Z-Gaps
Inspect the Z-Gap readings for each print jet. If any of the print jets have an incorrect Z-gap, they will need to be leveled again.
NOTE: The Closed Z-Gap (A) and the Open Z-Gap (B) are two
di󰀨erent measurements but should be read together.
Correct Closed Z-Gap
The Closed Z-Gap bars (B) should touch the baseline (A). This should be
consistent with the calibration print for each print jet.
A B
A
B
B
