3.4 Installation
3.4.1 INSTALLING THE CAMERA – INSTALLATION WITHOUT BRACKET
Installation Template
CAUTION: Installation template’s image size scale in this installation guide is not 1:1. The correct-size
template paper can be found inside the product packaging.
M o unting tem p la te
 4.92 in.
(125 mm)
 .255 in. (6.5 mm)
