3xLogic VX-2A-B-IWD

Hardware and Installation Manual| VISIX V-Series All-in-One Cameras – Gen I
12000 Pecos Street, Suite 290, Westminster, CO 80234 | www.3xlogic.com | (877) 3XLOGIC
56
5.4 Installation
5.4.1 INSTALLING THE CAMERA – INSTALLATION WITHOUT BRACKET
Installation Template
CAUTION: Installation template’s image size scale in this installation guide is not 1:1. The correct-size
template paper can be found inside the package separately.
Torx Wrench
Screw &
Plastic Anchor-3pcs
Quick Installation Guide
Installation Template
Adaptor & AC Plug
WALL CUSHION
CABEL CORE
Ø2.72 in. (69 mm)
3 - Ø0.26 in. (6.5 mm)
