3xLogic VX-2A-B-IWD User Manual

Hardware and Installation Manual| VISIX V-Series All-in-One Cameras – Gen I
12000 Pecos Street, Suite 290, Westminster, CO 80234 | www.3xlogic.com | (877) 3XLOGIC
61
5.6 Full Camera Specifications
Camera Module
Array Size
206x156
Detection Type
Uncooled vanadium oxide microbolometer
Sensor pixel size
12um
Spectral Response
7.8 ~ 14
Lens
4mm, F1.2 (FOV:36
o
), 6.8mm F1.2(FOV:20
o
), N/A FOV:58
o
),
Sensitivity
Less than 100mK
Video
Compression Format
H.264 and MJPEG Selectable per Stream
Number of Streams
Dual Stream, Configurable
Resolution
4:3 Mode
QVGA(320x240), VGA(640x480), NTSC(720x480), PAL(720x576), SVGA(800x600)
16:9 Mode
320x180, 480x270, 640x360, 800x450, 960x540, 1120x630, 1280x720
Frame Rate
Max. 9FPS in all resolutions
Motion Detection
Built-in
Burnt-in Text (Digital)
Time stamp and text caption overlay
Analogue Output
-
Audio
Input/output
1/1 channel
Compression Format
G.711
Function
Digital Input/output
1/2 channel
RS-485
-
Network
10/100 Base-T
Power over Ethernet
(PoE)
Supported
Protocol
QoS Layer 3 DiffServ, TCP/IP, UDP/IP, HTTP, HTTPS, RTSP, RTCP, RTP/UDP,
RTP/TCP, mDNS, UPnP™, SMTP, DHCP, DNS, DynDNS, NTP, SNMPv2c/v3(MIB-II),
IGMP, ICMP, SSLv2/v3, TLSv1, SRTP, RTMP
Storage
1 x microSDHC card embedded
