3xLogic VX-2A-B-IWD User Manual

Hardware and Installation Manual| VISIX V-Series All-in-One Cameras – Gen I
12000 Pecos Street, Suite 290, Westminster, CO 80234 | www.3xlogic.com | (877) 3XLOGIC
17
2.6 Full Camera Specifications
Camera Module
CMOS
Image Sensor
SONY EXMOR 1/2.9” 1080p CMOS
Effective Pixels
1920x1080
Scanning system
Progressive scanning
Electrical
Resolution
1920 x 1080
Min. Illumination
Color: 0.7 lux, BW: 0 lux (IR LED On)
AGC Control
Auto
Lens
3.0(w) – 9.0mm(t), F1.5(w) – F2.5(t), Optical 3x
Day & Night
Removable IR Cut Filter
Wide Dynamic
Range
Digital WDR
IR Illuminator
IR LED
High Power IR LED x 12 (850nm)
IR Working
Distance
Max. 30m (98ft)
Video
Compression
Format
H.264 and MJPEG Selectable per Stream
Number of
Streams
Dual Stream, Configurable
Resolution
1920x1080, 1280x720, 1120x630, 960x540, 800x450, 640x360, 480x270,
320x180
Compression FPS
30fps@1080p
Motion Detection
Built-in
Burnt-in Text
(Digital)
Time stamp and text caption overlay
Analogue Output
NTSC/PAL
Audio
Input/output
-
Compression
Format
-
Function
Digital
Input/Output
1/1 channel
RS-485
Not supported
Network
10/100 Base-T
Power over
Ethernet (PoE)
Supported
