Steps:
1). Place the installation template included in the
package on the desired installation surface.
2). Drill two holes in the correct positions based
on the paper mounting template, insert the
plastic anchors into the holes, and tighten
them into the holes.
3). Loosen the two bolts on the dome cover with
the provided torx wrench (T-10) to open the
dome cover.
4). Connect necessary cables including a LAN cable
and a power cable to the camera.
5). Place the camera body to match the alignment
holes with the provided plastic anchors, and
hold the camera against the surface where the
camera will be mounted.
6). Tighten the plastic anchors with the provided
screws (M4x20).
7). Once you can see the video on the camera,
adjust the angle of the camera. Refer to
Adjusting Angle of the Camera for more details.
8). Place the dome cover on the camera's main
body to close the dome cover. Dome cover has
two alignment holes that match the camera
body’s alignment holes.
9). Once properly placed, tighten the bolts with
the provided torx wrench (T-10).
10). As the last step, insert the white plugs into the
screw holes on the dome to keep the dome
cover neatly.
CAUTION: To prevent products from damage, place the
camera on stable and non-vibrating surfaces If the
stability is in doubt, consult safety personnel for
reinforcements, and then proceed with the installation.
