5). Connect your LAN (or PoE) cable from the ceiling pipe to the LAN connector on the camera,
and insert the camera into the pendant mount cap. Then, fix the camera to the pendant
mount cap by inserting the bolts (M4x8L) to the alignment holes on the pendant mount cap
and tightening them with the hex wrench included in the camera package.
6). For the last part of the installation, refer to steps 7 to 10 in Section 4.4: Installing the Camera
– Installation without Bracket in this manual.
