3xLogic VX-2A-B-IWD User Manual

Hardware and Installation Manual| VISIX V-Series All-in-One Cameras – Gen I
12000 Pecos Street, Suite 290, Westminster, CO 80234 | www.3xlogic.com | (877) 3XLOGIC
78
Function
RS-485
-
Network
10/100 Base-T
Power over
Ethernet (PoE)
Supported
Protocol
QoS Layer 3 DiffServ, TCP/IP, UDP/IP, HTTP, HTTPS, FTP, RTSP, RTCP, RTP/UDP,
RTP/TCP, mDNS, UPnP™, SMTP, DHCP, DNS, DynDNS, NTP, SNMPv1/v2c/v3(MIB-
II), IGMP, ICMP, SSLv2/v3, TLSv1, SRTP, RTMP
SD Slot
1 x microSD memory card slot
(SD/SDHC up to 32 GB supported)
※ Card not included
(Class 4 and higher recommended for HD recordings)
Electrical Characteristics
Power Source
DC 12V (Class 2, LPS) / PoE IEEE802.3af (Class 0)
Power
Consumption
6W @ DC12V
Video Output
-
Audio Input
-
Audio Output
-
D/I
Max 50mA@5VDC, TTL level 1.5V threshold
D/O
Max 50mA@24VDC
On-state resistance:50 Ω (max continuous)
Environment Condition
Operating
Temperature
Operating Range
[DC12V] [PoE]: -10 ˚C ~ 50 ˚C (14˚F ~ 122˚F)
Operating
Humidity
Up to 85% RH
Mechanical Condition
Material
Polycarbonate
Color
Main Unit: White
Camera Unit: Black
Dimension
28.1(Ø) x 25 mm
Weight (Approx.)
Main Unit: 225g (0.50lbs)
Camera Unit: 250g (0.55lbs)
