3xLogic VX-3M-F-AWD Installation Manual

Installation Manual v3.1 | VISIX S-Series Network Camera
12000 Pecos Street, Suite 290, Westminster, CO 80234 | www.3xlogic.com | (877) 3XLOGIC
107
9.19 Wall Mount Bracket for VX-2V-MD-RIWH (VX-WM-127)
83.5 mm (3.3")
83.5 mm
(3.3")
46 mm
(1.8")
85.7 mm
(3.4")
183.5 mm
(7.2")
158 mm (6.2")
6× M4
Depth:8 mm (0.3")
232 mm (9.1")

3xLogic VX-3M-F-AWD Specifications

General

Brand	3xLogic
Model	VX-3M-F-AWD
Category	Security Camera
Language	English
