3xLogic VX-3M-F-AWD

Installation Manual v3.1 | VISIX S-Series Network Camera
12000 Pecos Street, Suite 290, Westminster, CO 80234 | www.3xlogic.com | (877) 3XLOGIC
78
Number
Description
1
Dome cover
2
Lens group
3
Tilt adjusting screw
4
Status
indicators
Power
indicator
Solid red: power on
Network
indicator
Blue flicker: active
network
communication
Others: abnormal
5
Memory card slot
6
Reset
7
Alarm input/output cable
8
10M/100M/1000M self-adaptive Ethernet port
9
Power supply interface
10
RS-485 interface
11
Audio output
12
Audio input
13
Safety rope
14
Grounding screw
15
Expansion screw hole
NOTE: Press RESET about 10s when the camera is powering on or rebooting to restore the default settings,
including the user name, password, IP address, port No., etc.
AVAILABLE MOUNTS
 180° Wall Mount Bracket (3xLOGIC Product #: VX-8S-180-BWM)
 180° Pendant Mount Bracket (3xLOGIC Product #: VX-8S-180-BPM)
 Universal Corner Mount (3xLOGIC Product #: VX-CM)
 Universal Pole Mount (3xLOGIC Product #: VX-POLE)
