Installation Manual v3.1 | VISIX S-Series Network Camera
12000 Pecos Street, Suite 290, Westminster, CO 80234 | www.3xlogic.com | (877) 3XLOGIC
58
6.3 VX-6S-OD3-RIAWD, VX-3S-OD3-RIAH
CAMERA DESCRIPTION
Camera Overview
10 11
12
2
3 4 5
6
7 8 9
13
14
15
1
Camera Components
Number
Description
1
Black Liner
2
Bubble
3
Power Interface
4
Alarm Output A
5
Alarm Output B
6
Grounding
7
Alarm Input
8
Alarm In
