The interfaces on the rear panel are shown below:
Overview (3)
Overview (4)
Description of Overview (2~3)
Number
Description
Number
Description
1
Black Liner
2
Bubble
3
Lens
4
BNC Interface
5
Reset
6
Status Indicator
7
Test Serial Port
8
Micro SD Card Slot
9
Adapter Plate
10
Side Outlet
10
9
