Note: When choosing a wall mounting bracket, you must pay attention to the size of the cap which should
match the mounting base of the camera.
Size of the Mounting Base
Steps:
1. Route the cables, install the wall mounting bracket, and secure the cap on the bracket.
Wall Mounting
Bracket
Cap
Install Wall Mounting Bracket
2. Align the screw holes of the mounting base with the corresponding screw holes of the cap.
Cap
Mounting
Base
