Installation Manual v3.1 | VISIX S-Series Network Camera

12000 Pecos Street, Suite 290, Westminster, CO 80234 | www.3xlogic.com | (877) 3XLOGIC

a. Loosen the adjustable nut on the bracket.

b. Adjust the panning angle [0~360°] of the camera.

c. Adjust the tilting angle [0~90°] of the camera.

d. Rotate 0~360° to adjust azimuth angle of the image.

e. Tighten the adjustable nut to complete the installation.

3-axis Adjustment

Adjustable

Nut

T Direction

R Direction

P Direction
