AX Series for SharePoint 2010 Deployment Guide
45
9.7.2 CONFIGURE VIP WITH HTTP/PORT 80
1. Navigate to Config Mode > Service > SLB > Virtual Server.
2. “Select” VIP Name and click “edit”.
3. In the port section, click “Add”
4. Select Type: “HTTP”
5. Port: “80”
Figure 52: VIP Configuration
6. Click OK and then click Save to store your configuration changes.
9.7.3 APPLY AFLEX SCRIPT TO VIP
7. Navigate to Config Mode > SLB > Virtual Server.
8. Click on the VIP name WS-VIP.
9. In the Port section, select "80" and click Edit.
10. From the aFleX drop-down list, select “Redirect”.
11. Click OK and then click Save to store your configuration changes.
Figure 53: aFleX Configuration
