AX Series for SharePoint 2010 Deployment Guide
7
4 AX DEPLOYMENT FOR SHAREPOINT 2010 SERVER ROLES
Figure 1: Provides server description for the test environment:
Figure 1: SharePoint Server Role Matrix
5 ACCESSING THE AX SERIES LOAD BALANCER
This section describes how to access the AX Series device. The AX can be accessed either from a
Command Line Interface (CLI) or Graphical User Interface (GUI):
 CLI – Text-based interface in which you type commands on a command line. You can access the
CLI directly through the serial console or over the network using either of the following protocols:
 Secure protocol – Secure Shell (SSH) version 2
 Unsecure protocol – Telnet (if enabled)
 GUI – Web-based interface in which you click to access configuration or management pages and
type or select values to configure or manage the device. You can access the GUI using the
following protocol:
