31
MODGAS-XWR2 Technical Guide
LCD SCREENS
Setpoint Screens
Setpoint Screens
Refer to the following map when navigating through the Setpoint
Screens. From the SETPOINTS Screen, press <ENTER> to
scroll through the screens and change setpoints. Use the <UP>
and <DOWN> arrow keys to change your selections. Then press
<ENTER> to save the new setpoint.
WARNING: The <ENTER> key must be pressed after
changing setpoints for your entries to be
saved for subsequent power-ups.
NOTE: When the MODGAS-XWR2 module is operating
in Communications Mode, these setpoint screens
will not appear on the LCD display because they
are controlled by the AAON unit controller.
SET
POINTS
SAT SP
40-200°F
HEATING SUPPLY AIR TEMPERATURE SETPOINT
This is the target temperature while the heating is enabled. If you are
using the reset signal, this is the setpoint it will calculate to at zero
volts. Will display only in Stand-Alone Mode.
The SAT Setpoint is set by the LCD Display in Stand-Alone Mode
and is set by the AAON unit controller in Communications Mode.
Minimum Default Maximum
40ºF 120ºF 200ºF
5ºF 49ºC 93ºC
RESET SP
40-200°F
RESET HEATING SUPPLY AIR SETPOINT
This is the maximum temperature at which the Supply Air Temperature
will reset to. It will only display in Stand-Alone Mode.
The Reset Setpoint is set by the LCD Display in Stand-Alone Mode
and is set by the AAON unit controller in Communications Mode.
Minimum Default Maximum
40ºF 120ºF 200ºF
5ºF 49ºC 93ºC
To Next Page
