AAON MODGAS-XWR2 - Protected and Configuration Screens

33
MODGAS-XWR2 Technical Guide
MGAS XWR
1086vXXX
S/A MODE
SOFTWARE
1086 V.XXX
Hold for ve seconds.
CONFIG
ENTER TO
EXIT
Protected Screens Map
From the MODGAS Screen, press <ENTER> twice to get to
the SOFTWARE Screen. Then hold the <UP> button for ve
seconds. To scroll through the rest of the screens, press the
<MENU> button.
Conguration Screens
Refer to the following map when navigating through the
Configuration Screens. From the CONFIG Screen, press
<ENTER> to scroll through the screens and change setpoints. Use
the <UP> and <DOWN> arrow keys to change your selections.
Press <ENTER> to save any changes.
CONFIG
ADDRESS
1(138)
CURRENT BOARD ADDRESS
The rst number is the board address. The number in parentheses
is the E-BUS address. Use this screen to set the address for a Slave
board. Set the address to 2 for a slave board. Default is 1(138).
OPRATION
NORMAL
OPERATION MODE
Normal or Master. Default is Normal.
This screen is used to set a Primary MODGAS-XWR2 board as a
master board. If only using one MODGAS-XWR2 board, this should
be set to normal.
S/A MODE
AUTO
STAND ALONE MODE
Auto or Forced. Default is Auto.
In order for the MODGAS-XWR2 to communicate with another
MODGAS-XWR2 or 12 Relay Expansion board, the
MODGAS-XWR2 must be put in Forced Stand-Alone Mode.
STAGES
TOTAL XX
NUMBER OF TOTAL STAGES
Range is 1 to 19. Default is 2.
LCD SCREENS
Protected and Conguration Screens
