AAON RN Series User Manual

118
Table 56 - 26, 31-50, 60, and 70 ton Energy Recovery Wheel Filters
Feature 1A
Quantity / Size
Type
F, G, H, J, Q, R, S, T,
U, V, W, Y, Z, 1, 2, 3
(Prior to August 2014)
4 / 24” x 24” x 4”
Pleated, MERV 8
(After August 2014)
With V-Bank Outside Air Filters
OA - 8 / 24” x 18” x 2”
With Outside Air Preheat
4 / 24” x 24” x 4”
(Prior to August 2014)
With Energy Recovery Wheel
Exhaust Air Filters, Feature 6A - D,
F, G, H
OA - 4 / 24” x 24” x 2”
EA - 8 / 16” x 20” x 2”
(After August 2014)
With Energy Recovery Wheel
Exhaust Air Filters, Feature 6A - D,
F, G, H
OA - 8 / 24” x 18” x 2”
EA - 8 / 16” x 20” x 2”
4
(Prior to August 2014)
3 / 24” x 24” x 4”
(After August 2014)
With V-Bank Outside Air Filters
OA - 6 / 24” x 24” x 2”
With Outside Air Preheat
3 / 24” x 24” x 4”
(Prior to August 2014)
With Energy Recovery Wheel
Exhaust Air Filters, Feature 6A - D,
F, G, H
OA - 3 / 24” x 24” x 2”
EA - 6 / 16” x 20” x 2”
(After August 2014)
With Energy Recovery Wheel
Exhaust Air Filters, Feature 6A - D,
F, G
OA - 6 / 18” x 24” x 2”
EA - 6 / 16” x 20” x 2”

AAON RN Series Specifications

General

Category	Heat Pump
HSPF	Up to 10.0
Refrigerant	R-410A
Compressor Type	Scroll
Efficiency	High
Series	RN
Voltage Options	208-230/460V
Unit Weight	Varies with model
Dimensions	Varies with model
