AAON RN Series User Manual

15
RN Series Feature String Nomenclature
:
SIZE
VLT
CONFIG
A1
A2
A3
A4
B1
B2
B3
1A
1B
1C
1D
2
3
4
5A
5B
5C
6A
6B
6C
7
8
9
10
11
12
13
14A
14B
15
16
17
18
19
20
21
22
23
R
N
– 0 2 5 – 3 – 0 –
B
B
0 2 – 3 8 4 :
A
0 0 0 –
D
0
B
–
D
E
H
– 0
B
A
– 0
D
0 0 0 0
L
– 0 0 – 0 0
B
0 0 0 0 0
B
GEN
Model Options
Unit Feature Options
BASE MODEL
SERIES AND GENERATION
RN
UNIT SIZE
006 = 6 ton Capacity
007 = 7 ton Capacity
008 = 8 ton Capacity
009 = 9 ton Capacity
010 = 10 ton Capacity
011 = 11 ton Capacity
013 = 13 ton Capacity
014 = 14 ton Capacity
015 = 15 ton Capacity
016 = 16 ton Capacity
018 = 18 ton Capacity
020 = 20 ton Capacity
025 = 25 ton Capacity
026 = 26 ton Capacity
030 = 30 ton Capacity
031 = 31 ton Capacity
040 = 40 ton Capacity
050 = 50 ton Capacity
055 = 55 ton Capacity
060 = 60 ton Capacity
065 = 65 ton Capacity
070 = 70 ton Capacity
075 = 75 ton Capacity
090 = 90 ton Capacity
105 = 105 ton Capacity
120 = 120 ton Capacity
130 = 130 ton Capacity
140 = 140 ton Capacity
VOLTAGE
1 = 230V/1Φ/60Hz
2 = 230V/3Φ/60Hz
3 = 460V/3Φ/60Hz
4 = 575V/3Φ/60Hz
6 = 380V/3Φ/50Hz
8 = 208V/3Φ/60Hz
9 = 208V/1Φ/60Hz
INTERIOR PROTECTION
0 = Standard - Vertical Discharge and Return
A = Interior Corrosion Protection - Vertical
Discharge and Return
Model Option A: COOLING/HEAT
PUMP
A1: REFRIGERANT STYLE
0 = Air Handling Unit
B = R-410A - High Efficiency
C = R-410A - Standard Efficiency
E = R-410A Variable Capacity Scroll Compressor -
High Efficiency
F = R-410A Variable Capacity Scroll Compressor -
Standard Efficiency
G = R-410A Two-Stage Compressor - High
Efficiency
H = R-410A Variable Capacity Scroll Compressor +
Two-Stage Compressor - High Efficiency
K = R-410A Variable Speed Scroll Compressor -
High Efficiency
L= R-410A VFD Compatible Tandem Compressors
+ Microchannel Condenser
A2: UNIT CONFIGURATION
0 = No Cooling
A = Air-Cooled Cond. + Std Evap. Coil
B = Air-Cooled Cond. + 6 Row Evap. Coil
J = Water-Cooled Cond. + Std Evap. Coil
K = Water-Cooled Cond. + 6 Row Evap. Coil
P = Air-Cooled Cond. + 6 Row Evap. Coil + Mixed
Air Bypass
Q = Air-Cooled Cond. + 6 Row Evap. Coil + Return
Air Bypass
R = Water-Cooled Cond. + 6 Row Evap. Coil +
Return Air Bypass
T = Water-Cooled Cond. + 6 Row Evap. Coil +
Mixed Air Bypass
U = Chilled Water Coil - 4 Row
W = Chilled Water Coil - 6 Row
2 = Non-Compressorized + Std Evap. Coil
4 = Non-Compressorized + 6 Row Evap. Coil
6 = Air-Source Heat Pump
7 = Water-Source/Geothermal Heat Pump

AAON RN Series Specifications

General

Category	Heat Pump
HSPF	Up to 10.0
Refrigerant	R-410A
Compressor Type	Scroll
Efficiency	High
Series	RN
Voltage Options	208-230/460V
Unit Weight	Varies with model
Dimensions	Varies with model
