B2: HEATING DESIGNATION
0 = No Heating
1 = Heat 1
2 = Heat 2
3 = Heat 3
4 = Heat 4
6 = Heat 6
7 = Heat 7
8 = Heat 8
9 = Heat 9
A = Heat A
B = Heat B
C = Heat C
D = Heat D
E = Heat E
F = Heat F
G = Heat G
H = 1 Row Coil
J = 2 Row Coil
K = Heat K
L = Heat L
M = Heat M
N = Heat N
P = Heat P
B3: HEATING STAGING
0 = No Heating
1 = 1 Stage
2 = 2 Stage
3 = 3 Stage
4 = 4 Stage
5 = 5 Stage
6 = 6 Stage
7 = 7 Stage
8 = 8 Stage
9 = Modulating Gas/SCR Electric
A = Modulating/SCR Electric, 0-10V Control Signal
B = High Turndown Modulating Gas
H = Single Serpentine 8 fpi
J = Half Serpentine 8 fpi
K = Single Serpentine 10 fpi
L = Half Serpentine 10 fpi
M = Single Serpentine 12 fpi
N = Half Serpentine 12 fpi
Feature 1: RETURN/OUTSIDE AIR
1A: RETURN/OUTSIDE AIR SECTION
0 = Manually Adjustable OA Opening + RA Opening
A = Economizer
B = Econ + Power Exhaust
C = Econ + Power Return
D = Econ + PE - Discharge Damper Volume Control
E = Econ + PE - Discharge Damper Volume Control
+ 0-10V External Control
F = Low cfm Total Energy Recovery Wheel
G = Low cfm Total ERW + Bypass
H = Low cfm Sensible ERW
J = Low cfm Sensible ERW + Bypass
K = 100% Outside Air - No Return Air
L = Motorized Outside Air Damper + RA Opening
M = Motorized Outside Air Damper - No Return Air
N = Empty ERW Option Box - No Power Exhaust
P = Empty ERW Option Box + Power Exhaust
Q = 1% Purge Low cfm Total ERW
R = 1% Purge Low cfm Total ERW + Bypass
S = 1% Purge Low cfm Sensible ERW
T = 1% Purge Low cfm Sensible ERW + Bypass
U = High cfm Total ERW
V = High cfm Total ERW + Bypass
W = High cfm Sensible ERW
Y = High cfm Sensible ERW + Bypass
Z = 1% Purge High cfm Total ERW
1 = 1% Purge High cfm Total ERW + Bypass
2 = 1% Purge High cfm Sensible ERW
3 = 1% Purge High cfm Sensible ERW + Bypass
4 = Single Total Energy Recovery Wheel + Bypass
5 = 100% Return Air
