RN Series Feature String Nomenclature
:
SIZE
VLT
CONFIG
A1
A2
A3
A4
B1
B2
B3
1A
1B
1C
1D
2
3
4
5A
5B
5C
6A
6B
6C
7
8
9
10
11
12
13
14A
14B
15
16
17
18
19
20
21
22
23
R
N
– 0 2 5 – 3 – 0 –
B
B
0 2 – 3 8 4 :
A
0 0 0 –
D
0
B
–
D
E
H
– 0
B
A
– 0
D
0 0 0 0
L
– 0 0 – 0 0
B
0 0 0 0 0
B
GEN
Model Options
Unit Feature Options
Feature 2: OUTSIDE AIR CONTROL
0 = Standard - None
A = 3 Position Actuator - Sensible Limit
B = 3 Position Actuator - Enthalpy Limit
C = Fully Modulating Actuator - Sensible Limit
D = Fully Modulating Actuator - Enthalpy Limit
E = DDC Actuator
F = Constant Volume Outside Air
G = Options A + F
H = Options B + F
J = Options C + F
K = Options D + F
L = Options E + F
M = 3 Pos. Act. - Sensible Limit + CO2 Override
N = 3 Pos. Act. - Enthalpy Limit + CO2 Override
P = Fully Mod. Act. - Sensible + CO2 Override
Q = Fully Mod. Act. - Enthalpy + CO2 Override
R = DDC Actuator + CO2 Override
S = Dual Minimum Position Potentiometers + Fully
Mod. Act. - Sensible Limit
T = Dual Minimum Position Potentiometers + Fully
Mod. Act. - Enthalpy Limit
U = 2 Position Actuator
Y = Fault Detection and Diagnostics Controller
(FDD) Sensible Limit
Z = FDD Enthalpy Limit
1 = FDD Sensible Limit + CO2 Override
2 = FDD Enthalpy Limit + CO2 Override
Feature 3: HEAT OPTIONS
0 = Standard - None
E = Discharge Air Override
K = Auxiliary Heat K
L = Auxiliary Heat L
M = Auxiliary Heat M
N = Auxiliary Heat N
P = Auxiliary Heat P
Q = Auxiliary Heat Q
R = Auxiliary Heat R
S = Auxiliary Heat S
T = Auxiliary Heat T
U = Auxiliary Heat U
V = Auxiliary Heat V
W = Auxiliary Heat W
Feature 4: MAINTENANCE OPTIONS
0 = Standard - None
A = Field Wired 115V Outlet
B = Factory Wired 115V Outlet
C = Blower Aux. Contact
D = Remote Start/Stop Terminals
E = Options A + C
F = Options A + D
G = Options B + C
H = Options B + D
J = Options A + C + D
K = Options B + C + D
L = Options C + D
