RSMD Technical Guide
RSMD LCD SCREENS
13
RSMD Main Screens Map
Refer to the following map when navigating through the LCD Main
Screens. To scroll through the screens, press the <MENU> button.
RSMD
1067vxxx
SYSTEM
STATUS
SENSOR
STATUS
ALARMS
ALARM
HISTORY
SETPOINT
STATUS
Press to scroll through SYSTEM STATUS Screens.
Press to scroll through SENSOR STATUS Screens.
Press to scroll through SETPOINT STATUS Screens.
Press to go to SENSOR STATUS Screen.
Press to go to ALARMS Screens.
Press to go to ALARM HISTORY Screens.
Press to go to SYSTEM STATUS Screens.
Press to scroll through REFRIG MODULE Screens.
Press to scroll through ALARMS Screens.
Press to go to SETPOINT STATUS Screens.
Press to scroll through ALARM HISTORY Screens.
Main Screen Map & RSMD Module Screens
RSMD Module Screens
Refer to the following map when navigating through the RSMD
Screens. From the RSMD Screen, press <ENTER> to scroll
through the screens.
RSMD
1067vxxx
EBUS COMM
PACKETS
SOFTWARE
1067vXXX
BOARD/EBUS
ADDRESS
CURRENT SOFTWARE VERSION
You can access the protected
screens from this screen by holding
the <UP> button for 5 seconds.
CURRENT BOARD ADDRESS
E-BUS COMMUNICATION DIAGNOSTICS
Number of COMM packets received.
#COMP
CONFIGURED
# OF COMPRESSORS CONFIGURED
#COND
CONFIGURED
# OF CONDENSERS CONFIGURED
