AAON RSMD User Manual

RSMD LCD SCREENS
RSMD Technical Guide
16
FAN ON
XX PSI
Setpoint Status Screens
Setpoint Status Screens
Refer to the following map when navigating through the Setpoint
Status Screens. From the SETPOINT STATUS Screen, press
<ENTER> to scroll through the screens.
SETPOINT
STATUS
HEADPRSP
340 PSI
HEAD PRESSURE SETPOINT STATUS
Valid range is 275 to 475 PSI. Default is 340 PSI.
COILT SP
35 DEG
COIL TEMPERATURE SETPOINT STATUS
Valid range is 35 to 70 degrees. Default is 35 degrees.
LOW SUCTION PRESSURE SETPOINT STATUS
Default is 95 PSI.
LOW SUCT
95 PSI
IF CONFIGURED FOR MODULATING CONDENSER,
THE SCREEN BELOW WILL DISPLAY
IF CONFIGURED FOR FAN CYCLE,
THE TWO SCREENS BELOW WILL DISPLAY
FAN OFF
XX PSI
IF CONFIGURED FOR WATER SOURCE HEAT PUMP,
THE THREE SCREENS BELOW WILL DISPLAY
GLYCOL %
%
LOW H2O
37 DEGF
IF CONFIGURED FOR AIR TO AIR HEAT PUMP,
THE SCREEN BELOW WILL DISPLAY
DEFR INT
30 MIN
DEFROST INTERVAL SETPOINT STATUS
Default is 30 minutes.
GLYCOL PERCENTAGE STATUS
LOW LEAVING WATER TEMPERATURE SETPOINT STATUS
Default is 37 Degrees F.
HEAD PRESSURE READING WHEN FAN CYCLE IS ON
HEAD PRESSURE READING WHEN FAN CYCLE IS OFF
