AAON RSMD User Manual

RSMD LCD SCREENS
RSMD Technical Guide
14
System Status Screens
System Status Screens
Refer to the following map when navigating through the System
Status Screens. From the SYSTEM STATUS Screen, press
<ENTER> to scroll through the screens.
SYSTEM
STATUS
MODE OF
OPERATION
COMP A1-B1
OFF/
MODULATING %
COND 1 FAN
OFF/
MODULATING %
SYSTEM MODE OF OPERATION
Possible choices are
OFF, COOL, HEAT, DEHUMID, FORCE
COMPRESSOR A1, B1
(based on board address)
OFF / MOD POSITION
OFF: Compressor is off .
MODULATING PERCENTAGE: 0-100%
COMP A2-B2
ON/OFF
COMPRESSOR A2, B2
(based on board address)
ON, OFF, FORCE
ON: Compressor is on.
OFF: Compressor is off .
CONDENSER FAN 1
OFF, MOD POSITION
OFF: Condenser is off .
MODULATING PERCENTAGE: 0-100%
COMP A1-B1
FIXED OR DIG
COMPRESSOR A1 or B1 - Fixed or Digital
COMP A2-B2
FIXED OR DIG
COMPRESSOR A2 or B2 - Fixed or Digital
DEFROST
# MINUTES
DEFROST INTERVAL TIMER
# MINUTES
CONDENSER FAN 2
OFF, MOD POSITION
OFF: Condenser is off .
MODULATING PERCENTAGE: 0-100%
COND 2 FAN
OFF/
MODULATING %
IF CONFIGURED FOR AIR TO AIR HEAT PUMP
IF CONFIGURED FOR WATER SIDE ECONOMIZER BYPASS
BYPS VLV
CLOSED OR
% VALVE
OR
WATER SIDE ECONOMIZER BYPASS VALVE
CLOSED OR MOD POSITION
CLOSED: Valve is closed.
MODULATING PERCENTAGE: 0-100%
