AAON RSMD User Manual

RSMD Technical Guide
RSMD LCD SCREENS
15
H2O FLOW
YES/NO
WATER FLOW
YES/NO
IF CONFIGURED FOR WATER SOURCE HEAT PUMP
Sensor Status Screens
COMPTMP1
XX DEG
CALC CT1
XX DEG
SUCTION 1
XXX PSI
COMPRESSOR TEMPERATURE 1 READING FROM
HEAD PRESSURE 1 INPUT
CALCULATED COIL TEMPERATURE 1 FROM
SUCTION PRESSURE 1 INPUT
SUCTION PRESSURE 1 READING FROM INPUT
Sensor Status Screens
Refer to the following map when navigating through the Sensor
Status Screens. From the SENSOR STATUS Screen, press
<ENTER> to scroll through the screens.
SENSOR
STATUS
HEAD PR1
XXX PSI
HEAD PRESSURE 1 READING FROM INPUT
SUCTION 2
XXX PSI
SUCTION PRESSURE 2 READING FROM INPUT
HEAD PR2
XXX PSI
HEAD PRESSURE 2 READING FROM INPUT
CALC CT2
XX DEG
CALCULATED COIL TEMPERATURE 2 FROM
SUCTION PRESSURE 2 INPUT
COMPTMP2
XX DEG
COMPRESSOR TEMPERATURE 2 READING FROM
HEAD PRESSURE 2 INPUT
H2O TEMP
XX DEG
WATER TEMPERATURE READING FROM
LEAVING WATER TEMPERATURE SENSOR
IF CONFIGURED FOR WATER SOURCE HEAT PUMP
OR
