RSMD LCD SCREENS
RSMD Technical Guide
20
Diagnostic Screens
TMP3 VLT
X.XX
TEMPERATURE SENSOR 3 VOLTAGE
Displays the current voltage of the Leaving Water Temperature Sensor.
FORCE MODE
ON/OFF
FORCE MODE
Displays the current status of Force Mode. Values are ON/OFF.
RLY 1-5
ON/OFF
RELAYS 1 - 5 FORCE MODE
Press the <UP> and <DOWN> buttons to select ON or OFF
for each relay
AOUT-1 V
0.0-10.0
vdc
CONDENSER SIGNAL 1 FORCE
0.0 to 10.0 = Active Force Mode.
Press the <UP> and <DOWN> buttons to increase
and decrease the value.
AOUT-2 V
1.0-10.0
vdc
CONDENSER SIGNAL 2 FORCE
1.0 to 10.0 = Active Force Mode.
Press the <UP> and <DOWN> buttons to increase
and decrease the value.
IF FORCE MODE IS ON, THE FOLLOWING SCREENS
WILL APPEAR:
TRIAC 1
ON/OFF
BIN 1 - BIN 4
ON/OFF
BINARY INPUTS #1 - #4
Displays the current status of each Binary Input.
TMP1 VLT
X.XX
COIL TEMPERATURE SENSOR 1 VOLTAGE
Displays the current voltage of the 1st Coil Temperature Sensor.
TMP2 VLT
X.XX
COIL TEMPERATURE SENSOR 2 VOLTAGE
Displays the current voltage of the 2nd Coil Temperature Sensor.
TRIAC 2
ON/OFF
TRIAC 1
Displays the current status of Digital Compressor 1.
Values are ON/OFF.
TRIAC 2
Displays the current status of Digital Compressor 2.
Values are ON/OFF.
