RSMD Technical Guide
APPENDIX: CONDENSER OPTIONS
33
Single Condenser Per Two Modules
RSMD Main Confi guration Screen #2 -
Condenser Options
RSMD CONFIGURATION
Condenser Options
1 Cond for 2 RSMDs
USE < or > TO CHANGE
Select the “1 Condenser for 2 RSMDs” option on the above Hand
Held Service Tool Screen.
Figure 11: Prism 2 Condenser Confi guration
HVAC Unit Application
The One Condenser per Two RSMDs confi guration is used with the
following HVAC units:
• RLA BOX
• RLB BOX
• RLE BOX
To Next Page
