APPENDIX: CONDENSER OPTIONS
RSMD Technical Guide
38
Two Condensers Per Two Modules
RSMD Main Confi guration Screen #2 -
Condenser Options
RSMD CONFIGURATION
Condenser Options
2 Cond for 2 RSMDs
USE < or > TO CHANGE
Select the “2 Condensers for 2 RSMDs” option on the above Hand
Held Service Tool Screen.
Figure 16: Prism 2 Condenser Confi guration
HVAC Unit Application
The Two Condensers per Two RSMDs confi guration is used with
the following HVAC units:
• D-BOX 50-70 Ton
• D-BOX Air to Air Heat Pump
• D-BOX WSHP
To Next Page
