RSMD2R Technical Guide
LCD SCREENS
Conguration and Diagnostic Screens
Conguration Screens
Refer to the following map when navigating through the
Configuration Screens. From the CONFIG Screen, press
<ENTER> to scroll through the screens.
CONFIG
COND FAN
LOCKED/UNLOCKED
CONDENSER FAN LOCKED OR UNLOCKED
LOCK POS
100%
CONDENSER FAN LOCKED POSITION
Diagnostic Screens
Refer to the following map when navigating through the
Diagnostic Screens. From the DIAGNSTC Screen, press
<ENTER> to scroll through the screens.
DIAGNSTC
WDOG CNT
#
WATCHDOG TIMER
Displays the numbers of times the board has been reset due to
watchdog timer overview.
POWR CNT
#
POWER LOSS COUNT
Displays the numbers of times the board has been reset due to
power loss.
EPROM:
HOLD
DOWN
TO
LOAD
DEFAULTS
SP-1 VLT
X.XX
SUCTION PRESSURE SENSOR 1 VOLTAGE
Displays the current voltage of the Suction Pressure Sensor 1.
HP-1 VLT
X.XX
HEAD PRESSURE SENSOR 1 VOLTAGE
Displays the current voltage of the Head Pressure Sensor 1.
SP-2 VLT
X.XX
SUCTION PRESSURE SENSOR 2 VOLTAGE
Displays the current voltage of the Suction Pressure Sensor 2.
HP-2 VLT
X.XX
HEAD PRESSURE SENSOR 2 VOLTAGE
Displays the current voltage of the Head Pressure Sensor 2.
