RSMD2R Technical Guide
LCD SCREENS
Diagnostic Screens
BIN 1 - BIN 4
ON/OFF
BINARY INPUTS #1 - #4
Displays the current status of each Binary Input.
TMP1 VLT
X.XX
COIL TEMPERATURE SENSOR 1 VOLTAGE
Displays the current voltage of Coil Temperature Sensor 1.
TMP2 VLT
X.XX
COIL TEMPERATURE SENSOR 2 VOLTAGE
Displays the current voltage of Coil Temperature Sensor 2.
TMP3 VLT
X.XX
COIL TEMPERATURE SENSOR 3 VOLTAGE
Displays the current voltage of Coil Temperature Sensor 3.
FORCE MODE
ON/OFF
FORCE MODE
Displays the current status of Force Mode. Values are ON/OFF.
IF FORCE MODE IS ON, THE FOLLOWING
SCREENS WILL APPEAR:
RLY 1-5
ON/OFF
RELAYS 1-5 FORCE MODE
Press the <UP> or <DOWN> buttons to select ON or OFF for reach
relay.
TRIAC 1
ON/OFF
TRIAC 1
Displays the current status of Digital Compressor 1.
Values are ON/OFF.
TRIAC 2
ON/OFF
TRIAC 1
Displays the current status of Digital Compressor 2.
Values are ON/OFF.
AOUT-1 V
0.0-10.0
vdc
CONDENSER SIGNAL 1 FORCE
0.0 to 10.0 = Active Force Mode
Press the <UP> or <DOWN> buttons to increase and decrease the
value.
AOUT-2 V
1.0-10.0
vdc
CONDENSER SIGNAL 2 FORCE
0.0 to 10.0 = Active Force Mode
Press the <UP> or <DOWN> buttons to increase and decrease the
value.
