Aastra dialog 4224 Operator User Manual

Call Metering
BusinessPhone – Dialog 4224 Operator / Dialog 321450
Printout contents
Date: Shows the date of the printout.
Time: Shows the time of the printout.
Aastra Telecom Sweden
AB LM Ericssons väg 30
SE-126 37 Hägersten
Sweden
4 lines with 50 characters per line are free for definition. For
example, for the company address.
Reason for print out: This field shows if the printout was initiated only to read out the
counter or if the printout was caused because of a reset procedure.
Division: This field is prepared for future applications. Currently it always
shows Total system.
Group: Shows if the desired directory number(s) is (are) related to the
extension (caller) or trunk group.
Directory number
range:
Shows the directory number of the desired extension or trunk line.
When no directory number is entered then ALL will be shown in this
field and you will see all the counters of the extensions and trunk
lines on the display.
Currency: Shows the defined currency.
Dir.No.: Shows the directory number of the desired extension/trunk line.
Name: Shows the name of the extension or trunk line.
Pulses: Shows the accumulated pulses for the desired extension/trunk line
since the last reset.
Cost: Shows the accumulated cost for the desired extension/trunk line
since the last reset.
Cost/Pulse: Shows the actual price per pulse.
Tot al: Shows the accumulated pulses and cost of all the extensions/trunk
lines on the printout.

Aastra dialog 4224 Operator Specifications

General

Brand	Aastra
Model	dialog 4224 Operator
Category	Telephone
Language	English
