5.3.7.3 Inputs/outputs
The cabinet is available in the following format: RJ45 outputs
The following inputs/outputs exist on the front panel of each UCV2L motherboard:
1 DB9 connector for the debug link
1 DB25 connector for alarms and remote controls
1 RJ45 socket for connecting external on-hold music
2 RJ45 sockets for the primary and secondary DECT synchronisation ports
3 Ethernet ports (10/100 base T)
On UCV1L: 3 USB ports, one master and two slaves. On UCV2: 2 USB ports, slaves
control LEDs
the NMI/reset buttons
On UCV1L: 1 RJ45 port for connecting the printer (printer port not active from R5.1). This port
doesn’t exist on UCV2L
The following inputs/outputs exist on each power supply module, on the cabinet’s front
panel:
the 220V 50Hz mains connection socket
The following connectors are located at the back side of the cabinet:
A connector for expansion cabinet
A connector for battery’s link.
5.3.7.4 UCV2L motherboard
The basic cabinet contains the main UCV2L card, including:
1 control unit
3 Ethernet 10/100 BASE TX accesses
1 32-trunk matrix with dynamic addressing
1 voice mail system with 8 access points
1 Compact Flash Card (software of the Gateway and terminals, configuration’s data…); the
capacity of the COMPACT flash allows a new software release, a new firmware release of the
IP/SIP terminals to be downloaded and the buffer function (for tickets and billing) to be
integrated and the pictures storage. From version R5.1C, the memory size is 2Go. A new 4Go
compact Flash card is available with R5.4.
8 3-way conference circuits
4 alarm loop inputs and 4 alarm loop outputs
1 HDLC controller for setting up data communication in a B channel
1 voice prompt and synchronised announcements (on-hold, pre-off-hook)
The UCV2L card provides the interfaces with the following components:
one debugging console for the UCV2L card (1 DB9 console connector)
On UCV1L: 1 RJ45 port for connecting the printer (printer port not active from R5.1). This port
doesn’t exist on UCV2L
an external music source (RJ45 socket)
a general bell
alarm inputs (4)
Ethernet network: Ethernet 10/100 BASE TX accesses (1 LAN RJ45 connector), allowing the
connection of IP/SIP terminals, SIP Trunk network, i2070, TWP applications in CTI mode (VTI-
XML protocol), administration, etc.
the RUCV card of an expansion cabinet
