3
IP66
C – Within Environmental Limits
55°C
Max.
–20°C
Min.
B – Within Temperature Limits
Electrode
Maximum Distance
A – Maximum Distance of Instrument to Electrode
100m
3 MECHANICAL INSTALLATION
Fig. 3.1 Siting Requirements
3.1 Siting Requirements
Caution.
• Mount in a location free from excessive vibration.
• Mount away from harmful vapours and/or dripping fluids.
Information. It is preferable to mount the
instrument at eye level, allowing an unrestricted view of
the front panel displays and controls.
