SET UP RETRANS
–––––
Set Up Retrans 1
–––––
RTX Type 4-20
0-20
0-10
–––––
RTX Span (Units)
800
.
RTX Zero (Units)
200
.
…7 PROGRAMMING
7.5 Set Up Retransmission Page
– press to advance to next parameter
or
– press to advance to next page.
These two keys are used to advance to all subsequent parameters and pages. If a
parameter is changed it is automatically stored on operation of either key.
Retransmission 1 Page Header
Retransmission 1 Output Current Range
The retransmission 1 output can be selected from three mA current ranges to ensure
compatibility with the peripheral device connected.
Select the current range required for retransmission 1 output.
Retransmission 1 Span
Set the required retransmission 1 span output. This is adjustable to between 2.00 and
14.00 (pH) or –850 and 1000mV (Redox).
Retransmission 1 Zero
Set the required retransmission 1 zero output. This is adjustable to between 0.00 and
12.00 (pH) or –1000 and 850mV (Redox).
Note. The minimum range is any 2pH units within the 0.00 to 14.00 range (pH) or
150mV within the –1000 to 1000mV range (Redox)
.
Continued on next page.
