ABB 4630 - Mounting; Wall-;Pipe-Mounted Instruments

4
68 (2.68)
214
(8.43)
232
(9.13)
Fixing Centres
160 (6.3)
250
(9.84)
69 (2.72)
Fixing Centres
Allowance for
Cable Bends
200 (7.9)
42
(1.65)
61 (2
3
/ 8 ) O.D. Vertical or Horizontal Post
Dimensions in mm (in)
Mark fixing centres
(see Fig. 3.2)
Drill suitable
holes
Secure instrument to
wall using
suitable fixings
1
2
3
Position ‘U’ bolts on pipe
Position plates over ‘U’ bolts
Secure transmitter to mounting plate
Secure plates
1
2
3
4
A – Wall-mounting B – Pipe-mounting
…3 MECHANICAL INSTALLATION
Fig. 3.2 Overall Dimensions
Fig. 3.3 Wall-/Pipe-mounting
3.2 Mounting
3.2.1 Wall-/Pipe-mounted Instruments – Figs. 3.2 and 3.3
